什么是PImpl机制

Pointer to implementation（PImpl ），通过将类的实现细节放在一个单独的类中，从其对象表示中删除它们，通过一个不透明的指针访问它们（cppreference 是这么说的）

通过一个私有的成员指针，将指针所指向的类的内部实现数据进行隐藏

(相关资料图)

class Demo {
public:
	...
private:
	DemoImp* imp_;
}

为什么用PImpl 机制

个人拙见

C++ 不像Java 后端型代码，能有行业定式的列目录名形成规范（controller、Dao等）隐藏实现，降低耦合性和分离接口（隐藏类的具体实现）通过编译期的封装（隐藏实现类的细节）

业界实现

优秀开源代码有实现

PImpl实现

方法一

cook_cuisine.h

#pragma once
#include
#include
#include
//  Pointer to impl ementation
class CookImpl;
// 后厨
class Cook {
public:
    Cook(int, const std::vector&);
    ~Cook();
    std::vector getMenu();     /* 获取菜单 */
    uint32_t getChefNum();                  /* 获取厨师数量 */
private:
    CookImpl* impl_;
};
typedef std::shared_ptr CookPtr;		// 美妙的typedef 懒人工具

cook_cuisine.cc

#include "cook_cuisine.h"
class CookImpl {
public:
    CookImpl(uint32_t checf_num, const std::vector& menu):checf_num_(checf_num), menu_(menu) {}
    std::vector getMenu();
    uint32_t getChefNum();
private:
    uint32_t checf_num_;
    std::vector menu_;
};
std::vector CookImpl::getMenu() {
    return menu_;
}
uint32_t CookImpl::getChefNum() {
    return checf_num_;
}
Cook::Cook(int chef_num, const std::vector& menu) {
    impl_ = new CookImpl(chef_num, menu);
}
Cook::~Cook() {
    delete impl_;
}
std::vector Cook::getMenu() {
    return impl_->getMenu();
}
uint32_t Cook::getChefNum() {
    return impl_->getChefNum();
}

方法二

cook_cuisine.h

#pragma once
#include
#include
#include
#include "cook_cuisine_imp.h"
// 后厨
class Cook {
public:
    Cook(int, const std::vector&);
    ~Cook();
    std::vector getMenu();     /* 获取菜单 */
    uint32_t getChefNum();                  /* 获取厨师数量 */
private:
    CookImplPtr impl_;
};
typedef std::shared_ptr CookPtr;

cook_cuisine.cc

#include "cook_cuisine.h"
Cook::Cook(int chef_num, const std::vector& menu) {
    impl_.reset(new CookImpl(chef_num, menu));
}
Cook::~Cook() {
}
std::vector Cook::getMenu() {
    return impl_->getMenu();
}
uint32_t Cook::getChefNum() {
    return impl_->getChefNum();
}

cook_cuisine_imp.h

#pragma once
#include
#include
#include
class CookImpl {
public:
    CookImpl(uint32_t checf_num, const std::vector& menu):checf_num_(checf_num), menu_(menu) {}
    std::vector getMenu();
    uint32_t getChefNum();
private:
    uint32_t checf_num_;
    std::vector menu_;
};
typedef std::shared_ptr CookImplPtr;

cook_cusine_imp.cc

#include "cook_cuisine_imp.h"
std::vector CookImpl::getMenu() {
    return menu_;
}
uint32_t CookImpl::getChefNum() {
    return checf_num_;
}

main.cc

#include "cook_cuisine.h"
#include
using namespace std;    // Testing, 平时开发可千万别用这句
int main() {
    int checf_num = 10;
    const std::vector menus = { "Chicken", "Beef", "Noodle", "Milk" };
    CookPtr cook(new Cook(checf_num, menus));
    auto cook_menu = cook->getMenu();
    auto cook_checf_num = cook->getChefNum();
    cout << "======================Chinese Cook======================\n";
    cout << "============Checf: " << cook_checf_num << " people\n";
    cout << "==========Menu\n";
    for (size_t i = 0; i < cook_menu.size(); i++) {
        cout << "============" << i + 1 << " : " << cook_menu[i] << "\n";
    }
    return 0;
}

CMakeLists.txt
